Hand Shearing Machines like 8ch, 10ch bhaiyaan cutters, rod cutters shearing machines are used in large scale in workshop machinery and industrial machinery. We are stockist of all these kinds of shearing machines. Shown below are images of few with their specification of the type of size of metal they can cut.
The Plate and Section Shearing Machines are versatile in application. The shearing gives well defined passages for letting metal sheets and plates pass during shearing operations. A hand type long handle connects the pair of lever slides with the blade slide. The connection is effected by the insertion of the hand pin in the back hole for shearing full capacity materials and in the front hole for shearing lighter materials.
In addition to a rack and pinion arrangement the shearings are also equipped with ratchet gearing mechanism which reduces the physical effort appreciably. Light materials can be sheared by a direct push and pull of the lever which engages the gear pawl and disengages the pressure and locking pawl.
The group of plate and section shearing machine is fitted with one pair of plate shearing blades and one pair of section shearing blades. Sliding pieces of of section shearing blades can be adjusted by hand to make right-angle cuts on Angle and Tee section of different sizes. The accurately machined and uniform slide ways accommodate a heavy blade slide which operates vertically, without any play. Each machine is fitted with a swivel type down holder in the front and a feed-guide cum down-holder for sections in the rear.
Hand Shearing Machine, Metal Cutting Machinery, Bhaiyaan Cutter, Mumbai, India
Specifications for the above Hand Shearing Machine
1) The above machine is available in 12 inch (12″) and 16 inch(16″) blades.
2) The 12″ shearing machine can cut up to 3mm of M.S. sheets and 1.2 mm of stainless steel sheets, This 12″ Machine is around 40Kg
in weight and is our light duty machine.
3) We also have 12″ Heavy Shearing Machine which can be used to cut up to 5mm M.S. metal sheets and 4mm of stainless steel.
4) We also have Hand Shearing Machines of 16″ Blade. This Shearing Machine is used to cut M.S. Steel of upto 2mm thickness and 1mm stainless Steel. These shearing machines in lay man language are called as Bhaiyaan Cutters.
Contact Us For Price Or Queries. We are located in Mumbai, India
Hand Shearing Machine, Metal Cutting Machinery 8CH, Mumbai, India
8CH Hand Shearing Machine, Metal Cutting Machinery 10CH, Mumbai, India
Specifications for the above 8CH or Angle Cutting Machine, Shearing Machine
1) The above machine is called the 8CH or angle cutting shearing machine.
2) It is used to cut 1.5″ * 1.5″ angle cutting of M.S. Steel.
3) Cuts Angle cuts of up to 3mm
4) It is used to cut squares and round of up to 13mm thickness and sheets of upto 3mm thickness.
Contact Us For Price Or Queries. We are located in Mumbai, India
Hand Shearing Machine, Metal Cutting Machinery 10CH, Mumbai, India
Specifications for the above 108CH or Angle Cutting Machine, Shearing Machine
1) The above machine is called the 8CH or angle cutting shearing machine.
2) It is used to cut 2″ * 2″ angle cutting of M.S. Steel.
3) Cuts Angle cuts of up to 4mm
4) It is used to cut squares and round of up to 16mm thickness and sheets of up to 4mm thickness.
Hand Shearing Machine, Metal Cutting Machinery 10CH, Mumbai, India
Specifications for the above Rod Cutter Machine
1) The above rod cutter can be used to cut upto 25 or 32 mm steel or M.S. rods.
2) These are high speed blades and come with full gurantee
Apart from these machines the other shearing machines like 47R, G3/L we also deal in all other possible hand shearing as well as threadle shearing machines. We also keep trunk folding or metal folding machines and press.
G8L Hand Shearing Machine, Metal Cutting Machinery 10CH, Mumbai, India
G3L Hand Shearing Machine, Metal Cutting Machinery 10CH, Mumbai, India
33L Hand Shearing Machine, Metal Cutting Machinery 10CH, Mumbai, India
Contact Us For Price Or Queries. We are located in Mumbai, India
Metro is the big brand in manufacturing pag cutting machines. They are also manufacturers of profiling or profile gas cutting machines. They are experts at Hand Cutters, Heavy Duty Cutters, Heavy Duty Oxygen Regulators, LPG Heating Torches, Gas Cutting and Gas Cutting Trolly Machines.
The Extra Accessories that can be added along with the Lathe Machine is True Chuck, Dog Chuck, Chuck Plate, Face Plate, Steady Rest, Follow Rest, Rear Tool Post, Rear Guard, Revolving Center.. Apart from this other optical attachments that can be done are Taper Turning, Copy Turning, Spherical Turning, Milling Attachment, Thread Chasing.
